The Blackhawk Indoor Slim Ceiling antenna is designed for use in an In-Building Coverage system, such as those engineered by Powertec using the Cel-Fi GO. The antenna has been shaped to generate a 360° hemisphere of signal for complete internal coverage when mounted on the ceiling.
Indoor dome antennas are designed to be mounted to the ceiling of your building to provide consistently distributed mobile phone service from your Cel-Fi repeater / booster system. The thin white design allows the product to be nearly invisible when mounted, yet provides industry-leading increases for in-building coverage and capacity.
The Slim Series have the added advantage of being Horizontally Polarised to increase donor-service antenna isolation which is particularly important when installing systems in confined spaces such as demountable “donga” buildings.
ELECTRICAL SPECIFICATIONS
| Frequency Range | 698-960 MHz | 1690-2170 MHz | 2300-2500 MHz | 2500-2700 MHz |
| Peak Gain | 3 dBi | 4 dBi | 4 dBi | 5 dBi |
| VSWR | ≤1.8:1 | ≤1.8:1 | ≤1.8:1 | ≤1.8:1 |
| Polarization | Horizontal | |||
| PIM, 3rd Order, 2x20W | ≤-150 dBc | |||
| Horizontal Beamwidth | 360° | |||
| Vertical Beamwidth | 120° | 85° | 76° | 70° |
| Input Impedance | 50 Ω | |||
| Max.Power | 50 W | |||
| Lightning Protection | DC Ground | |||
MECHANICAL SPECIFICATIONS
| Connector | N-Female/ 4.3-10 Female | |||
| Dimensions | Ø190 x 7.3 mm | |||
| Weight | 0.25 kg | |||
| Colour | White | |||
| Reflector Material | PCB | |||
| Radome Material | ABS (UV Stabilized) | |||
| Operating Temperature | -40°C to +65 °C | |||
