The Blackhawk M2M omni antenna is a compact antenna capable of operating on any network in Australia, making it suitable for M2M communications on Telstra, Optus, and Vodafone TPG networks.
The antenna is most commonly used in machine telemetry, such as in smart metering, vending machines, and industrial control systems. This model has been selected on the basis of its high radiation efficiency and stable average gain across the operating frequency range.
With a height of only 82 mm, the antenna is also a fantastic option for low clearance vehicles, buses, and caravans. With a simple stud mount the antenna can be a great internal antenna for the Cel-Fi repeater system, in fact in multistory buildings or multi-level car parks the antenna makes for an excellent external antenna where multiple antennas must be mounted on the building roof.
4 dBi gain across lower bands 698-960 MHz
5 dBi gain across bands 1710-2170 MHz
4 dBi gain across upper bands 2500-2700 MHz
Black ABS construction
Bracket mount included
3 m cable with pre-terminated SMA male connector
Ideal for Telstra, Vodafone, and Optus M2M applications.
